Lehimlovchi temir quvvat manbai 21V

Model raqami

K18N-UP200S21

Chiqish

Chiqish kuchlanishi

ortiqcha 21V

Nominal oqim

9.5A

Joriy diapazon

0-9.5A

Nominal quvvat

199.5W

Dalgalanish shovqini

210mVp-p

Sozlanishi chiqish diapazoni

19.522.9V

Chiqish aniqligi

±1 percent

Chiziqni tartibga solish

±0.5 percent

Yuklash reglamenti

±0.5 percent

Sozlang, ko'taring, vaqtni to'xtating

500ms, 50ms, 20ms

Kiritish

Kirish kuchlanish diapazoni

90-264V AC

Kirish oqimi

5A/115V, 2.5A/230V

Kirish chastotasi

50/60 Gts

87 foiz

Shovqin oqimi

30A@230V

Oqish oqimi

<>

Himoya

Haddan tashqari yuk himoyasi

110200 foiz Turi: Hiqichoqni tiklash: avtomatik tiklash

Qisqa tutashuvdan himoya qilish

Turi: Hiccup Reset: avtomatik tiklash

Haddan tashqari harorat, himoya

Cover temp.>105 daraja, chiqish yopiq, avtomatik tiklash

Atrof-muhit

Ishlash harorati, namlik

-1050 daraja, 1090 foiz RH, kondensatsiya yo'q

Saqlash harorati, namlik

-2085 daraja, 1095 foiz RH

Harorat, Drift

±0.03 percent / degree (050 degree )

Tebranish

10500 Gts, 2G 10 min/ 1 sikl, HAR bir EKS UCHUN 60 minut.

SafetyEMC standartlari

Xavfsizlik standartlari

GB4943 EN62368

Chidamli kuchlanish

I/P{0}}O/P: 1,5KV; I/P-FG: 1,5KV; O/P-FG: 0,5KV DC 1min

Izolyatsiyaga qarshilik

I/P-O/P, I/P-FG, O/P-FG:500VDC/ 100M Om

EMC standartlari

GB9254 EN55022 SINF B

Boshqalar

Hajmi

1278245 mm

Og'irligi

0,5 kg
